Model ETM504
Columns Double Column
Load Capacity (kN) 50
Test Grade 0.5
Testing Force Accuracy ±0.5%
Testing Force Range 0.4%-100%FS
Force Resolution 1/300000
Displacement Accuracy ±0.5%
Displacement Resolution 0.05mm
Speed Range (mm/min) 0.01-1000
Control Accuracy ±0.5%
Max. compression testing Space(mm) 800
Test width (mm) 1200
Lower Compression Platen 1190*1190mm （customized)
Load Cell High-precision USA load cell offers high stiffness, high stability, and high linearity
Position limit switch Upper and lower lights
Power Supply AC220V±10%, 50Hz/60Hz
