Usable Energy: 50KWh

Cell Type: Super capacitor battery

Rated Voltage: 384V/DC

Rack Minimum Voltage: 312V/DC

Rack Maximum Voltage: 432V/DC

Dimensions (WxDxH): 750x730x1008 (mm)

ESR/AC @1KHz: <100mΩ

Max. Continuous Charge Current: 100A

Max. Continuous Discharge Current: 100A

Weight: 380Kg

Configuration: 108S6P

Discharge Temperature: -20℃ ~ +60℃

Charge Temperature: 0℃ ~ +55℃

Cooling Method: Natural cooling

Operating Humidity: 0 ~ 90% RH (Non-condensing)

Cells Self-discharge Rate: 2% per month

Projected Cycle Life (25℃): 20,000 times

Recommended Depth of Discharge: ≤ 90%

Maximum Depth of Discharge: 100%

Shell Material: Metal & ABS plastic

Monitoring Data: System voltage, current, temperature, SOC, SOH, cycle, cell’s voltage

Indicator Light Display: Capacity %

Environmental Protection: Customized

IP Grade: IP65

Storage Conditions: -20℃ ~ +40℃, 25% ~ 95% RH, SOC > 30%: One full charge needed per two months
